Concrete mixing bucket is a handy tool when you need to make concrete without electricity or when you need to transport or lift the concrete to a place hard to access. The bucket is equipped with a screw shaft and a guard grill on the bucket. Available in two sizes: a 210 l capacity bucket (two versions: emptying from the bottom hatch in the middle of the bucket, or on the left of the bucket), and a larger 320 l concrete mixing bucket, intended for 700 and 800 series, is now available. It is equipped with emptying in the middle of the bucket. Hatch opening is powered by a hydraulic cylinder controlled with an electric directional valve, operation from driver’s seat with an electric switch.
The bucket is also equipped with a flexible 1350 mm emptying tube which mounts on the bottom
hatch. This enables pouring of the concrete further away from the bucket.
|Total width||1490 mm||1700 mm|
|Screw shaft diameter||400 mm||480 mm|
|Volume||210 l||320 l|
|Empty weight||299 kg||420 kg|
|Weight at max. capacity||794 kg||1188 kg|
|Unloading hatch diameter||180 mm||180 mm|
|Emptying tube length||1350 mm||1350 mm|
|Product no., emptying in the middle||A36473||A447861|
|Product no., emptying on the left||A37241||–|
